Extension Bernapark, Deisswil

2020

Line

The former cardboard factory in Deisswil near Bern is beginning a new era. Thanks to the wooden multi-storey top-up and the conversion of the existing factory buildings, a new quarter is created.

Aerial view during the construction zoom
Aerial view during the construction
Aerial view during the construction zoom
Aerial view during the construction
Balcony during the construction phase zoom
Balcony during the construction phase
Steel plate to transmit the forces zoom
Steel plate to transmit the forces

The Project

In Deisswil near Bern, more than 250 employees once produced cardboard for the whole of Switzerland before those responsible shut down the machines in 2010.

Today, a new quarter is being built with 173 apartments for around 300 residents as well as 25,000m² of office and commercial space.


The venerable factory buildings are still of good quality.

They were therefore not demolished, but refurbished and converted, and extended by two stories with a wooden extension. In this way, a new, diverse neighborhood was created. For more information, visit www.bernapark.ch.


The Construction

The listed factory buildings consist largely of reinforced concrete structures with large window fronts. For the extension, wood is used almost exclusively: all walls and floor slabs are made of prefabricated wooden elements.


The Challenges
The elevation always had to adapt to the winding factory buildings. Consequently, the derivation of the acting forces is not quite trivial. The structural engineers defined points where the forces of the extension could be introduced. Different load-bearing directions of the floor elements with sometimes large spans were the result. Stuberholz called in Timbatec for the development of the demanding structural analysis concept and for quality assurance.

Construction Data

- 173 Apartments


Construction costs

- BKP 1-9: approx. 55 million Swiss francs

- BKP 214: 7 million Swiss francs


Services Timbatec

- SIA Phase 32 Construction project
- SIA Phase 51 Implementation project
- SIA Phase 52 Design

Architecture
GHZ Architekten AG,
3123 Belp

Building Owner
Berna Industrie- und Dienstleistungspark AG,
3066 Stettlen

Timber Construction Engineers
Timbatec Holzbauingenieure Schweiz AG,
3012 Bern

Timber Construction
Stuber & Cie AG,
3054 Schüpfen

Civil Engineer
ingenta ag,
3006 Bern

General Contractor
Implenia Schweiz AG,
3000 Bern
